Schneider Electric XS1M30KP340L1 PLC Programmable 5m Inductive Proximity Sensor

About this item

This is a Schneider Electric OsiSense XS1 general-purpose inductive proximity sensor, model XS1M30KP340L1, built in a fixed M30 cylindrical body (60 mm) that's flush-mountable for tight installations. It senses at 10 mm nominal distance and offers a programmable discrete output (1 NO or 1 NC) through a 4-wire, 5-meter cable. Runs on 12-24V DC with reverse polarity protection, handles up to 200 mA with overload/short-circuit protection, and carries an IP68 double-insulation rating for harsh environments.

• Schneider Electric OsiSense XS1 inductive proximity sensor, model XS1M30KP340L1
• Cylindrical M30 body, 60 mm length, flush-mountable design
• 10 mm nominal sensing distance (Sn), programmable 1 NO or 1 NC discrete output
• 4-wire cable connection, 5 m cable length
• 12...24 V DC supply with reverse polarity protection, switching capacity ≤200 mA with overload and short-circuit protection
• IP68 double-insulated rating per IEC 60529

Specifications

MPN

XS1M30KP340L1

Brand

Schneider

Model

XS1M30KP340L1
