Shear Bolt Gearbox 35-45HP by Rancher Supply - Rotary Replacement Kit for Omni Gear RC30 with 5 Extra Shear Bolts, Lubricant Not Included

About this item

This Rancher Supply shear bolt gearbox is a direct replacement for light-duty rotary cutters rated 35-45HP, built to fit Omni Gear RC30 and a wide range of other models including RD5, RD6, RZ160, Razorback, Rhino, Hardee, and Mohawk units. It uses a 1-3/8" smooth input shaft and a 1.57" 12-spline output shaft, with a 1:1.47 ratio suited for cutters 5 feet or larger. Heat-treated internals and high-speed bearings are built for long service life, and the kit comes with a blade carrier mounting nut, cotter pin, and 5 extra shear bolts. Note: it ships dry and needs 16 oz of 90W or 85W140 gear lube to run.

• Replacement shear bolt gearbox rated 35-45HP for light-duty rotary cutters, includes 5 extra shear bolts.
• Fits Omni Gear RC30 and many others: RD5, RD6, RZ160, RZ60 (P/N 00786192), Razorback BH4/BH5/BH6 series, BMB 1080/10300, Hardee C1378, Mohawk 14-500, Rhino 0711050100/71105, Omni 250123/250001, SE Big Ox 1970, Sidewinder 26272.
• 1-3/8" smooth input shaft with 1/2" shear bolt hole and retaining ring groove; 1.57" 12-spline tapered output shaft.
• 1:1.47 gear ratio built for rotary cutters 5 feet or larger in diameter.
• Heat-treated gears and shafts with high-speed ball bearings, four-bolt mounting, plus blade carrier nut and cotter pin included.
• Ships dry — needs 16 oz of 90W or 85W140 gear lube (not included).

Specifications

ASIN

‎B082WKLHHT

Item Weight

‎45.4 pounds

Manufacturer

‎Rancher Supply

Best Sellers Rank

#85,073 in Patio, Lawn & Garden (See Top 100 in Patio, Lawn & Garden) #366 in Agricultural Machinery Spare & Replacement Parts

Item model number

‎401-0007AB

Package Dimensions

‎13.5 x 13.2 x 13.1 inches

Date First Available

‎December 18, 2019
